REFERENCE STANDARDS :
Reference Tube Coupling Standards For Metric Tube Only.
- ISO 8434-1 : 24° Cone Bite Type
- BS 5200 : 60° Hose End
- IS 8805 : 24° Cone Bite Type
- DIN 2353 : 24° Cone Bite Type
- ISO 8434-4 : 24° Cone With Weld on Nipples.
SPECIFICATIONS :
- Body and Nut Material : Steel
- Ferrule : Heat Treated Steel
- Seal Material : Copper Washer, Bonded
- Seal, Elastomeric Seal.
- O' Rings : Nitrile / Viton.
Surface Treatment : CR3(Trivalent Plating)
REFERENCE PORT CONNECTOR STANDARDS :
- SAE J 1926/1 : SAE (UNF/UN) Threads, 'O' Ring Seal.
- ISO 1179 : BSPP (G) Threads, Flat Face.
- BS 5380 : BSPP (G) Threads, 'O' Ring Seal.
- ISO 6149 : Metric Threads, 'O' Ring Seal.
EXAMPLE
Description :
- Male Stud Coupling. 16mm Tube OD Heavy Series, G 1/2" BSPP, With Elastomeric Seal,Complete with Nut & Ferrule, With CR3 Plating.
- Male Stud Coupling. 12mm Tube OD Light Series, G 3/8" NPT, without Nut & Ferrule, With CR3 Plating.
